Suntech home textile suitings fabric packing machine
Categories

Suntech home textile suitings fabric packing machine

Suntech home textile suitings fabric packing machine
Suntech home textile suitings fabric packing machineSuntech home textile suitings fabric packing machineSuntech home textile suitings fabric packing machineSuntech home textile suitings fabric packing machine
CategoriesAutomatic Fabric Packing Machines
AlbumView larger image
BrandSuntech
ModelST-CBPM
TypeVacuum Packing Machine
ConditionNew
ApplicationApparel, Machinery & Hardware, Textiles
Packaging TypeFilm
Packaging MaterialPlastic
Automatic GradeAutomatic
Driven TypeElectric
VoltageAs customized
PowerAbout 2.2KW
Dimension(L*W*H)1100X440X150mm(for standard model only)
FOB portNINGBO&SHANGHAI
Terms of PaymentL/C, D/P, T/T, Western Union
Update Time2021-03-04
Contact Now
Favorites
Detail Information
Video
Technical Specifications
Features
Packing
Suntech Fabric Cardboard Packing Machine
ST-CBPM is used to pack card board bolts from the Fabric Folding & Lapping Machine, which is widely applicable for home textiles, suitings, etc. Advantages like savings in Labour cost, in time taken for loading & unloading, clarity of goods for customs-inspection, moisture & dust proof packing etc., attract both the exporters & importers.
Model
ST-CBPM
Standard Packing Size
1100x440x150mm(LXWXH)
Packing Material
POF. Max. Film Width: 800mm;Thickness:13-30 microns
Packing Capacity
5-20pcs/min
Machine Dimensions(LXWXH)
 2200x1250x1500mm(for standard model)
Compressed Air Pressure
5-7bar
Electric Specs Remark
Single Phase -220V, 50HZ (can be adjusted to suit
    for different countries)
Remark
Variable working width is possible and can be tailor-made to your requirements of processing needs.
1). The cardboard bolts could be transported by the Inlet Conveyor or manually to the Main Packing Unit for both width and side sealing through a polythene film.
2). The length of the incoming cardboard bolts are detected by the sensitive photoelectric sensor; while the width and height could be adjusted by handle so as to ensure there will be no polythene film wastage during packing .
3). On the completion of the side sealing, the packed cardboard bolts could be transferred to the Heat Chamber so as to crimp the polythene tightly over the cardboard bolts, which ensures a vacuum packing effect .
4). The complete system is PLC controlled; Easy for Operation.
5). Protective Device and Safety Controls are bulid in the machine; Safe and Reliable.
6). Option: Inlet Conveyor,: Heat-shrink Machine, Roller Conveyor and Fabric Stage.
