PERFECTLY FIT FOR ULTRA-WIDE WEAVING MACHINES, EASIER TWIN BEAM HANDLING
Features of Electric Warp Beam Lifting Trolley (For Ultra-wide Looms)
● Central Hook Support, Simplify Twin Beam Loading, 1 Operator Enough
● Heavy Capacity, Compact Model, Operation with High Efficiency in Narrow Space
● User-friendly Design, Makes Easy Handling and Stable Operation
● Fully Electric, Fast Charge with Long-lasting Power, Use with Confidence
Central Hook Support, Simplify Twin Beam Loading, 1 Operator Enough
Heavy Capacity, Compact Model, Operation with High Efficiency in Narrow Spaces
User-friendly Design, Makes Easy Handling and Stable Operation
Fully Electric, Fast Charge with Long-lasting Power, Use with Confidence
European Standard, Craftsmanship of Ingenuity
ST-MBT-02II SPECIFICATIONS
| Carrying Capacity | 3000 kgs (Bottom Beam) 300 kgs (Heald Frame) |
Lifting Height | 700 mm (Bottom Beam) 1950 mm (Heald Frame) |
| Beam Flange Diameter | 800-1000 mm |
Lifting / Driving | 5 Motors |
| Battery | 24 V/200 Ah |
| Application | Adapt to Any Loom |
